Renishaw M4 kit for TP7M Styli in Box with 90 Day Warranty A-5000-7829

MSRP: $1,614.00
$1,100.00
(You save $514.00)
(No reviews yet) Write a Review
Condition:
Used
Weight:
5.00 LBS
Shipping:
Calculated at Checkout

Product Description

Condition:

Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended.





Country of Manufacture:   UNITED KINGDOM

Brand:    RENISHAW

Model:    M4 KIT FOR TP7M STYLI

MPN:   A-5000-7829





Item Description

Renishaw M4 kit for TP7M Styli in Box with 90 Day Warranty.


Renishaw List Price $1614.00

Selecting & Using Styli

renishaw-thread-styli-options-.jpeg   renishaw-styli-material-options-.jpeg

In principle, styli are the CMM’s “tools”, providing the same relationship that turning tools have with lathes, and milling and boring tools have with milling machines.

When measuring with a touch-trigger probe, the machine uses the stylus to take the data points on the surface of the work piece.

Each touch generates a point that is defined using coordinate values in X, Y and Z. Feature, size, form and position can then be computed from these points.

By contrast a scanning probe takes continuous readings along the surface of a work piece. Sophisticated software uses this data to compute the size, position and form of features on the component.

Carefully select the stylus best suited to your measurement application


Outcome

The probe calibration procedure establishes the stylus tip’s effective diameters when measuring, and their positions in relation to one another and to the machine’s co-ordinate system.


The CMM compensates for the stylus position & tip dimensions. This leaves just the form of the stylus tip as the only factor influencing the measurements

What's in the M4 TP7M Stylus Kit

renishaw-m4-kit-for-tp7m-styli-kit-part-list-image-.jpeg  renishaw-m4-kit-for-tp7m-styli-kit-part-list-.jpeg

Overall length

Renishaw uses a standard description of overall length, measured from the rear mounting face of the stylus to the centre of the ball.

Effective working length (EWL)

This is measured from the centre of the ball to the point at which the stem will foul against the feature when measuring 'normal' to the part.

EWL can also be affected by assembly tolerances. For this reason Renishaw styli are assembled to exacting standards in controlled conditions.

This is by far the best price you will find on a Renishaw M4 kit for TP7M Styli in Box with 90 Day Warranty. Purchase with confidence from a Paypal verified retailer.

If what you order is not what you receive you will be refunded the full purchase price of this sale.

Metrology Parts would like the opportunity to earn your business for this sale and all of your future Renishaw needs.

If you have any questions feel free to contact us. With 36 plus years of experience with Renishaw products we can help with all of your application needs as well as your after sales support.
