Renishaw XR20-W Machine Tool Rotary Axis Calibrator & 90 Degree OARS Mount Kit A-9920-0400 A-9920-0700

$19,500.00
(No reviews yet) Write a Review
Weight:
25.00 LBS
Shipping:
Calculated at Checkout

Product Description





***CALIBRATED FEBRUARY 2021***





Condition:

Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended.





Country of Manufacture:   UNITED KINGDOM

Brand:   RENISHAW

Model:   XR20-W ROTARY AXIS CALIBRATOR OARS BRACKET

MPN:   A-9920-0400 A-9920-0700





Item Description

Renishaw XR20-W Wireless Rotary Axis Calibrator Factory Calibration February 2021 and 90 Degree OARS Bracket Mounting Kit with 1 Year Warranty.



                                                                         XR20-W rotary axis calibrator

Renishaw Current List Price:

XR20-W:    $25,115

90 Degree OARS Mounting Kit:    3,776



XR20-W rotary axis calibrator

Rotary axis positioning is critical to overall machine accuracy



Rapid calibration using XR20-W provides up to ±1 arc second accuracy

The XR20-W rotary axis calibrator works in conjunction with XL-80 and XM-60 laser systems. It consists of an integrated angular retroreflector mounted on a precision servo-controlled axis. The angular position of the axis, and the optics relative to the main body housing, is controlled by a very high accuracy encoder system with the scale directly machined on the main bearing.



Features and benefits

  • Flexible and light weight – designed for single handed easy fitment to a wide variety of rotary tables, lathes and other rotary axes
  • High accuracy - ±1 arc second using XL-80 or ±1.2 arc second using XM-60. (See error budget and uncertainty calculation below for further details).
  • Rapid testing - quick test setup and fast data capture
  • Wireless operation – powered by rechargeable batteries and integrated wireless connection using Bluetooth® communication
  • Built-in alignment targets – minimises measurement errors during setup
  • Auto calibration – pre-measurement calibration cycle compensates for angular alignment errors
  • Pre-test cycles – automatic direction and feedrate detection
  • Feedrate - speeds of up to 10 rpm


The XR20-W addresses the need for quick and easy testing on a wide range of machines and axis types.

It does this by keeping all the features that made its RX10 predecessor a success, but adding a much simpler set up and operation.



Easy to use mounting options

Mounting the XR20-W to rotary axes is simplified using a range of modular mounts to suit different applications.



Standard mounting

Centration on the axis is typically very simple, using the markings around the circumference of the mounting ring and the centration aid.



Flexible mounting

As well as the standard mounting arrangement, a mounting ring adaptor plate enables the XR20-W to be fitted to rotary tables with unsuitable centre recesses. It can also be used to secure the XR20-W to the chuck (lathe) adaptor and custom mounts.



Software

CARTO software suite is used for rotary measurement using XL-80 laser or XM-60 multi-axis calibrator and is made up of three applications:

  • Capture to collect data and generate part programs.
  • Explore to provide powerful analysis and create reports to international standards.
  • Compensate to generate compensation files for improved positioning accuracy.

Off axis rotary software* provides a solution for five axis machine calibration where the XR20-W cannot be mounted on the machines rotational axis. The software outputs part programs for synchronised movement of rotary and linear axes to maintain beam alignment throughout the test.

*Only compatible with RotaryXL and LaserXL software





                                                                                                       Product A-9920-0700, XR20-W 90° bracket kit





XR20-W 90° bracket kit

The XR20-W 90° bracket provides a high specification mounting solution for both 'on' and 'off' axis rotary measurement. The bracket can be mounted with the removable high power magnetic feet or a variety of through holes for direct bolt attachment. The kit is supplied in a heavy duty transport case.
Note: Off axis rotary software is not supplied.



This is by far the best price you will find on a Renishaw XR20-W Wireless Rotary Axis Calibrator Factory Calibration February 2021 and 90 Degree OARS Bracket Mounting Kit with 1 Year Warranty.

Purchase with confidence from a Paypal verified retailer.

Why pay retail prices when you can purchase from Metrology Parts.

If what you order is not what you receive you will be refunded the full purchase price for this sale.

Metrology Parts would like the opportunity to earn your business for this sale and all of your future Renishaw product needs.

If you have any questions feel free to contact us. With 34 plus years of experience with Renishaw products we can help with all of your application needs as well as your after sales support.
