We offer a great selection of Renishaw Products. We also focus on products related to CMMs as well as Vision Systems like Ram Optical and OGP. We thank you for the opportunity to earn your business and strive for your 100% satisfaction.
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully
Country of Manufacture: UNITED KINGDOM
Brand: RENISHAW
Model: MH20I
MPN: A-4099-0100
Fully Tested with 90 Day Warranty Renishaw MH20I Manual Indexible CMM probe Head.
This very nice MH20I was just taken in on trade for a motorized PH10 system.
Whats included in this sale is one MH20I probe head with a 90 day warranty.
If your application requires a shank or TP20 Modules please do not hesitate contacting us for a complete package to suit your application.
MH20i is a manually adjustable probe heads that combines the TP20 kinematic stylus module mount with two axis indexing.
The A-axis rotates through ±180° in the X-Y plane. The B-axis rotates through 90° in the Z plane. A lever locks the head in one of up to 168 repeatable positions, set at 15° increments.
The head is capable of carrying the full range of TP20 modules, which can be changed without re-qualification, providing qualification has taken place in each position with each stylus/module combination.
| Specification | |
|---|---|
| Length | 61 mm |
| Diameter | 48 mm |
| Weight | 210 g |
| Probe mounting | TP20 kinematic mount |
| Head mounting | MS range of shanks |
| Suitable interface | PI 4-2 |
| No. of probe sockets | 1 |
| Probe status indication | 1 LED |
| Cable connection | 5 pin DIN 180º socket |
| A-axis indexing | 0° to 90° in 15° repeatable steps |
| B-axis indexing | 180° in 15° repeatable steps |
| Repeatability of position | 1.5 µm (0.00006 in) (TP20 and 10 mm stylus fitted) 2.5 µm (0.0001 in) (EM2 extended module and 10 mm stylus) |
| Maximum extension bar | EM2 extension module - 75 mm (2.95 in) |
This is by the far the best price you will find on a Fully Tested with 90 Day Warranty Renishaw MH20I Probe Head.
Why pay retail prices when you can purchase with warranty from Metrology Parts.
Purchase with confidence from a Paypal verified retailer.
If what you order is not what you receive you will be refunded the full purchase price for this sale.
Metrology Parts would like the opportunity to earn your business for this sale and all of your future Renishaw needs.
If you have any questions feel free to contact us. With 32 plus years of experience with Renishaw products we can help with all of your application needs as well as your after sales support.
